KOBE® Brillia® Series 36" Stainless Steel Island Range Hood


Model #:

ISX2136SQB-2

At a Glance

Product Dimensions 42.13"h x 35.75"w x 23.63"d

KOBE Brillia island range hood is equipped with 3-speed mechanical push button, dishwasher-safe baffle filters, and LED lights. It is a powerful hood with 680 CFM internal blower yet quiet at 1.0 sone on QuietMode.Read More

Request a Quote

Appliance Fit Width (in.):36

Get to know this product.

Product Overview

Product Overview

This range hood is crafted with 20-gauge commercial grade stainless steel and features a beautiful seamless design. The duct cover is adjustable to fit different ceiling heights.

QuietMode™: At 280 CFM, this unique feature allows the KOBE range hood to operate at a reduced sound level of 40 decibels (1.0 sone).

Blower Type: Single Horizontal Squirrel Cage

Speed / Control: 3-Speed / Mechanical Push Button

CFM / Sone: 280 / 1.0 / QuietMode™, 450 / 2.2 / Low, 680 / 5.0 / High

Exhaust: Top 6″ Round

Light: The hood is equipped with 3W LED lights

Filters: Dishwasher safe professional baffle filters allow for easy cleaning.

Attractive Appearance: The seamless curves and stylish appearance of the hood will compliment any kitchen.

Easy to Clean: KOBE’s unique design, which includes easy to empty catch areas and smooth hood surface, lets you clean the fans without disassembling the hood.

Quality: Parts are checked for defects and designed for trouble free long term use.

Easy to Install: Our special design makes installation fast and easy.

colour: Commercial Grade Stainless Steel

Duct Cover: ISX21DC-2 (included in all ISX21 Series)

Duct Cover: ISX21DC37-O (included in ISX21 SQB-DC37-2 only)

Ceiling Height: With ISX21DC-2 duct cover, it fits ceiling height between 8′ to 9-1/2′

Ceiling Height: With ISX21DC37O outer duct extension, it fits ceiling height between 9-1/2′ to 10-1/2′

Useful Documents
Specifications

General Specs

Width (in.)35.75
Height (in.)42.13
Duct Size (in.)6" Round (15.24cm)
Depth (in.)23.63
CollectionBrillia
ColorStainless Steel
Appliance Fit Width (cm.)91
Color/Finish NameStainless Steel
Manufacturer Warranty1 Year Labor / 2 Year Parts
Range Hood TypeIsland
ADA CompliantNo
ENERGY STAR CertifiedNo
Outdoor ApprovedNo
Appliance Fit Width (in.)36
Smart CompatibleNo
Maximum CFM680
Grease Filter TypeBaffle
Bulb TypeLED
Sones Rating1.0 - 5.0
Fan Speed Options3
Vent LocationTop
Height Above Cooktop30 - 36
Ventilation DirectionVertical
Width (cm)90.81
Height (cm.)107
Depth (cm.)60.01
Height Above Cooktop Centimeter76.20 - 91.44
Amp2.5
Noise Level (Sones)Standard - (High)
Ventilation TypeDucted

Additional Information

ControlMechanical Push Button
QuietMode™1.0 Sone
ECO ModeNo
Ceiling (Min)8 feet
Ceiling (Max)9.5 feet
Fits Ceiling Heights8', 8.5', 9', 9.5', 10', 10.5'
